Vibrocultivator tine 2489 70x12mm "Herkules" type

Vibrocultivator tine 2489 70x12mm "Herkules" type

Vibrocultivator tine 70x12mm "Herkules" type. Available with 10 and 12 metric thread for fitting to a wide range of cultivators and also pre-assembled with the Bellota 15035 cultivator point. Can be mounted on 80x80mm frames with just the tine or on 70x70 frames with the Bellota 2489-R reinforcement. Various clamp models available for 70x70 and 80x80mm frames.

Main product specifications

Ref.	G	A	B	C	D	E	F	M	Grs.	B	D	S
2489 C2A	70x12	505	667	292	15			M10	8700	90		2489R
2489 C2A+15035 CA	70x12	576	667	292	15	576	100	M10	9950	90	100	2489R
2489 C2A A12	70x12	505	667	292	15		100	M12	8700	90	100	2489R

D Made-to-order products.

Clamps. See page

Concave head.

2489 C2A fits with 1529 See page / 1530 M10 See page / 1535 S CN CA1 See page / 15035 See page / 15038 See page / 15045 See page

2489 C2A A12 fits with 1530 M12 See page / 1535 S CN See page / 1599 S CN See page / 15035 CP CA1 See page

Reversible point for vibro cultivator 1529

Reversible point for vibro cultivator 1529

Reversible point for vibro cultivator 1530

Reversible point for vibro cultivator 1530

Reinforced reversible point 1535 for cultivators

Reinforced reversible point 1535 for cultivators

Reversible point 15035 for Vibrocultivator tine

Reversible point 15035 for Vibrocultivator tine

Swallow Point 15038 for Cultivator Tine

Swallow Point 15038 for Cultivator Tine

Reversible point 15045 for cultivator

Reversible point 15045 for cultivator

Sweep 1599 for Vibro Tine

Sweep 1599 for Vibro Tine

CLAMPS DEPENDING ON THE CHASSIS

Ref.	60x60	70x70 Solo brazo	70x70 con refuerzo	80x80
2489 C2A	12489-6060	12489-7070 / KITBAS7070BR70	KITBAS7070BR70	12489-8080 / KITBAS8080BR70

FRAME WHERE FITS

Ref.	BASTIDOR MÁXIMO (mm)	BASTIDOR MÁXIMO (mm)
2489	80x80	70x70
