Bellota Fitting coulters — ref. KUHN
Main product specifications
| Ref. | Original Ref. | Model | ø " | ø mm | C | Center Hole Code | No. Bolt holes | |
|---|---|---|---|---|---|---|---|---|
| 8114R393LG | N02831A0 | Plano con bisel simple | 14" | 351 mm | 3 | R | 39 mm | 6 |
| 8116R674ON | Plano con bisel simple | 16" | 404 mm | 4 | R | 67 mm | 4 | |
| 8116R684OP | 110034 | Plano con bisel simple | 16" | 406 mm | 4 | R | 68 mm | 4 |
| 8115R324LAROB | N00875A0 | Plano con bisel simple | 15" | 381 mm | 4 | R | 324 mm | 6 |
| 8320M5EE | 110029 | Plano con bisel doble muescado | 20" | 508 mm | 5 | 6 | ||
| 90174E9 | 10033 | 55 ondas | 17" | 433 mm | 4 | 6 | ||
| 9017R664FH | 110014 | 55 ondas | 17" | 433 mm | 4 | R | 66 mm | 5 |
| 9318R104E9 | 110036 | 8 ondas | 18" | 457 mm | 4 | R | 10 mm | 6 |
| 95184E9 | 110032 | 13 ondas | 18" | 454 mm | 4 | 6 |
