Quivogne stubble cultivator assembly

The wing 1586-A has an angle of attack of 21º and the wing 1586-B of 15º. Both are offered in 8 and 12 mm thickness with different hole configurations. It can be mounted with the double heart cultivator 1577, with the point and shin 1587-1588 and with the reversible point 1571.
1587-A 1587-B

Main product specifications

Ref. C Grs. R A B C D E M B D
1586-A 8 CA 8 4500 21º 480 300 70 128 1199A M12 70 100
1586-A 8 CA2 8 4500 21º 480 300 45-75 128 1199A M14 70 100
1586-A 8 CA3 8 4500 21º 480 300 45-75 128 1199A M12 70
1586-A 12 CA 12 6900 21º 480 300 70 128 1199A M12 60 100
1586-A 12 CA1 12 6900 21º 480 300 70 128 1199A M14 60
1586-A 12 CA2 12 6900 21º 480 300 45-75 128 1199A M14 60 100
1586-A 12 CA 2 10" 12 4500 21º 10" (254) 300 45-75 128 1199A M14 125 100
1586-A 12 CA3 12 6900 21º 480 300 45-75 128 1199A M12 60
1586-B 8 CA 8 4500 15º 480 300 70 128 1199A M12 70 100
1586-B 8 CA3 8 4500 15º 480 300 45-75 128 1199A M12 70 100
1586-B 12 CA1 12 6900 15º 480 300 70 128 1199A M14 60 100
1587-A 10 CA 10 1650 15º 120 215 1199A M12 500
1587-B 10 CA 10 1650 15º 120 215 1199A M12 500 100
1587-B 12 CA 12 1980 15º 120 215 1199A M12 350 100
1587-B 12 CA1 12 1980 15º 120 215 1199A M14 350
1588 10 CA 10 2200 100 290 1199A M12 300
1588 10 CA1 10 2200 100 290 1199A M14 300

D Made-to-order products.

1587-A more aggresive angle of attack than 1587-B

References 1586-B 8 CA and 1586-A 12 CA 2 10" are painted black; the rest of the references are red.

Fits in stubble tine

Ref.2444-865 A12 CA1 / 2444-865 A12 CA2 / 2444-865 A12 CA52444-865 A14 CA1
1586 CA + 1587 CA + 1588 CAM12x70
1586 CA1/CA2 + 1577 CA1M14x70
